| Audio Integrated | YES |
| Expansion Ports | PS/2 RJ-45 USB 2.0 USB 3.0 Audio jack(s) Optical S/PDIF Out |
| Firewire Connection | 0 |
| Graphic Card | NO |
| Highlights | Remote GO! - One-stop PC Remote Control and Home Entertainment USB BIOS Flashback - Easy, Worry-free USB BIOS Flashback with Hardware-based Design DirectKey - A Dedicated Button to Access the BIOS Directly Dual Intelligent Processors - TPU + EPU. Network iControl - Real-time Network Bandwidth Control UEFI BIOS - Flexible & Easy BIOS Interface USB 3.0 Boost - Faster USB 3.0 Transmission with UASP |
| Integrated Vga | NO |
| Internal Connector | 1 x 24-pin EATX Power connector(s) 1 x 8-pin ATX 12V Power connector(s) 1 x Clear CMOS jumper(s) 1 x Front panel audio connector(s) (AAFP) 1 x MemOK! button(s) 1 x System panel(s) 1 x TPM connector(s) 6 x SATA 6Gb/s connector(s) 1 x USB 3.0 connector(s) support(s) additional 2 USB 3.0 port(s) (19-pin) 1 x USB BIOS Flashback button(s) 1 x COM port(s) connector(s) 3 x USB 2.0 connector(s) support(s) additional 6 USB 2.0 port(s) 1 x CPU Fan connector(s) (4 -pin) 1 x DirectKey Button(s) 3 x Chassis Fan connector(s) (4 -pin) 1 x DRCT header(s) 1 x S/PDIF out header(s) |
| Length (cm) | 30.5 |
| Link | http://www.asus.com/Motherboards/M5A97_R20/ |
| Maximum Memory (gb) | 32 GB |
| Memory Bus | DDR3-1066 DDR3-1333 DDR3-1600 DDR3-1866 DDR3-2133(OC) |
| Memory Technology | non-ECC Dual channel un-buffered |
| Mini-pci Slots | 0 |
| Motherboard Chipset | AMD 970 |
| Multi Processor Support | NO |
| Nic | 10/100/1000 |
| Parallel Ports | 0 |
| Pci Express 16x | 1 - x16 mode 1 - x4 mode |
| Pci Express 1x | 2 |
| Pci Express 4x | 0 |
| Pci Express 8x | 0 |
| Pci Slots | 2 |
| Product Description | ASUS Dual Intelligent Processors, Extreme USB 3.0 Transfer Speed, and Windows 8 on AMD 970 |
| Ps/2 Connectors | 2 |
| Raid | YES |
| Raid-controller | RAID 0, 1, 5, 10 |
| Sata 3 Gb/s | 0 |
| Sata 6 Gb/s | 6 |
| Sata Connectors | 6 |
| Serial-ports | 0 |
| Socket | SOCKET AM3+ |
| Speaker Support | 8 SPEAKERS |
| Supports Cpu | AMD AM3+ FX/Phenom II/Athlon II/Sempron 100 Series Processors AMD Cool 'n' Quiet Technology Supports AM3+ 32 nm CPU Supports CPU up to 8 cores Supports CPU up to 140 W |
| Total Memory Slots | 4 |
| Usb 2.0 | 6 |
| Usb 3.0 | 2 |
| Usb 3.1 | - |
| Usb-ports | 8 |
| Width (cm) | 22.9 |
